Atlona AT-USB-EX100-KIT USB extender over CATx 100 metres
Item No.
AT1200
- Point-to-point USB extender kit
- Extends USB signals up to 330 feet (100 meters) over a single category type twisted pair cable
- USB 2.0 compatibility
- Transmitter features USB type B interface for connection to a host PC, plus two USB type A ports for peripheral devices
- Receiver features four USB type A ports for peripheral devices
- USB 2.0 compatibility with a maximum data rate of 315 Mbps supported over HDBaseT
The AtlonaAT-USB-EX100-KITis a high speed USB extender kit. It supports extension of USB 2.0 data up to 330 feet (100 meters) using a single, cost effective Category-type twisted pair cable. The AT-USB-EX100-KIT is ideal for popular conferencing applications such as Zoom®and Microsoft®Teams®. The AT-USB-EX100-KIT is comprised of locally powered transmitter and receiver endpoints. USB 2.0 compatibility with a maximum data rate of 315 Mbps supported over HDBaseT
Description
- Point-to-point USB extender kit
- Extends USB signals up to 330 feet (100 meters) over a single category type twisted pair cable
- USB 2.0 compatibility
- Transmitter features USB type B interface for connection to a host PC, plus two USB type A ports for peripheral devices
- Receiver features four USB type A ports for peripheral devices
- USB 2.0 compatibility with a maximum data rate of 315 Mbps supported over HDBaseT
The AtlonaAT-USB-EX100-KITis a high speed USB extender kit. It supports extension of USB 2.0 data up to 330 feet (100 meters) using a single, cost effective Category-type twisted pair cable. The AT-USB-EX100-KIT is ideal for popular conferencing applications such as Zoom®and Microsoft®Teams®. The AT-USB-EX100-KIT is comprised of locally powered transmitter and receiver endpoints. USB 2.0 compatibility with a maximum data rate of 315 Mbps supported over HDBaseT
Specifications
| Brand | Atlona |
| Product category | USB extenders over CATx |
| Connections | RJ45, USB |
| Connections (in) | RJ45 female (x1), USB A female (x4) |
| Connections (out) | RJ45 female (x1), USB A female (x2), USB B female (x1) |
| Extender category | 51-100 m |
| Max. extension distance | 100 m |
| Extension cable | CATx (x1) |
| Extension connector | RJ45 |
| Extension protocol | HDBaseT |
| Other signals | USB 2.0 - HighSpeed (Enhanced) |
| USB version | USB 2.0 - HighSpeed (Enhanced) |
| Power supply | External power supply |
| Included | two power supplies, wall/table mounting brackets, and installation guide |
| Brand item no. | AT-USB-EX100-KIT |
| EAN code | 8716065469080 |
